LPS 1175 Security Doors

A red ribbon with a white border on a white background.

Certified protection for critical infrastructure

When security is critical, you need a door that has been independently tested and proven to perform. LPS1175 security doors from TS Designs provide certified protection against forced entry while delivering the durability and reliability required for demanding environments.

Manufactured from high-grade aluminium and stainless steel, our doors are engineered for long-term performance with virtually limitless service life. Designed with a fit-and-forget philosophy, they require no ongoing maintenance, helping reduce both operational disruption and whole-life costs.

LPS 1175: Issue 8 Security Rating B5 (SR2) or C5 (SR3) security doors are independently tested and certified by the Loss Prevention Certification Board (LPCB) to resist forced entry using a range of attack tools.


Available in a range of security ratings, including:


  • SR2 – Medium security protection
  • SR3 – Enhanced protection for higher risk environments


This ensures compliance with security specifications for utilities, infrastructure, transport and government facilities.


Offered with a 20 year warranty for peace of mind (conditions apply).

Please scroll through tabs for more

  • Hinged or removable over panels
  • Removable side panels
  • Vision panels. Unit size range: 170mm to 1100mm wide & 170mm to 1400mm high
  • Louvre vents with or without insect/vermin mesh. Unit size range: 125mm to 900mm wide & 125mm to 900mm high
A brown door is on the side of a brick building.
A brown door is on a brick wall next to a concrete walkway.
A brown door with a push to open sign on it
A large white building with a blue roof is sitting in a parking lot.

Configurations

A red ribbon with a white border on a white background.
A black and white drawing of different types of windows.
A white door with a push to open sign on it.
PS2 Steel Security Doorsets

The most comprehensive range of steel security doorsets on the market accredited to B5 (SR2) LPS 1175 Issue 8.

A green door with a stainless steel lock on it
PS3 Steel Security Doorsets

The most comprehensive range of steel security doorsets on the market accredited to C5 (SR3) LPS 1175 Issue 8.

Specifications

A red ribbon with a white border on a white background.
Market Leading Certified Features
  • Largest door leaf size range, up to a colossal 1600mm in width and 3275mm in height
  • Widest range of doorset configurations available
  • Thinnest and lightest door leaves. Only 45mm thick and weighing no more than 45kg/m2. Less than half the weight of some of our competitors
  • The greatest number of MICO High Security Locking Systems and functions listed in the LPCB Red Book for any doorset product with a choice of single point , 2-point or 3-point locking systems
  • Unlimited structural opening sizes when specified with adjacent over panels and side panels
  • Factory fitted hardware throughout
  • Choice of alternative colours to each face of door leaf as standard
  • No quibble, long term product warranty scheme
Certified Options
  • LPS 1175: Issue 8 Security Rating B5 (SR2) or C5 (SR3)
  • Magnelis® corrosion resistant mild steel or stainless steel substrates
  • Single, double or odd-leaf double doorset configurations
  • Hinged or removable over panels
  • Removable side panels
  • Vision panels up to 1100mm wide x 1400mm high
  • Louvre vents up to 900mm wide x 900mm high, with or without insect/vermin mesh
  • Panic escape, emergency escape, manual deadlocking, automatic deadlocking or electro-mechanical deadlocking functionality
Certified Performance
  • CE marked in accordance with external door standard EN 14351-1: 2006 & A2: 2016
  • LPS 1175: Issue 8 Security Rating Classifications B5 (SR2) and C5 (SR3)
  • Secured by Design product listed and accredited
A logo that says bespoke made in the uk
A logo for sustainably manufactured products with a door and arrows.
A logo that says `` designed for maximum security '' with a shield and a chain.
A logo that says zero to low maintenance with a wrench in a circle.

Security you can trust

A red ribbon with a white border on a white background.
If you would like to know more about our security door solutions and how we can help you reduce your through-life costs and carbon emissions, please send us your details and the issues you would like us to address.
